Machine Features :

1. Cutting range 45° Or 90°.
2. 400 mm Carbide Freud brand italian saw blade supplied with machine to insure quality cutting.
3. Diameter of a diamond saw blade is 400 mm (Which can Replace with 300 mm, 350mm & 450 mm As Per Requirement).
4. Machine provides vibrationless operation wich gives precision cutting angle.
5. Machine consumes less power for operating.
6. For security purpose; In the case of Over Voltage Machine is treap Automatically.
7. Adjustable cutting speed with Digital display unit.
8. For Up and down operation of blade; Standerd Equiped with Road – Bush & Helical Rack-Pinion System.
9. 25 mm Base plate makes with Grinding and hard chrome process.
10. PLC base Automation Delta brand software panel wich is online repairable.
11. Automatic Inbuilt Diesel Spray wich Increase life of saw blade,gives smoodh & mirror finish cutting.
12. Indicator light for availibility of Diesel.
13. Saw blade cover system protect blade & collect waste aluminium particles in the tray.
14. Comply with branded SKF bearing with machine.
15. This is ideal machine to cut uneven & odd shaped profile due to 4 manual clamp position setting.
16. Machine is equipped with the 2 Horizontal & 2 Verticle manual clamp for Optimum grip.
17. Machine deliver with Tool kit.
18. In optional extra accessories, roller stand, roller track with measuring tap fitting, DRO length gauge & safety cover.

Technicial Specifications:
