Machine Features :

1. Cutting range 45° Or 90°.
2. 400 mm Carbide Freud brand italian saw blade supplied with machine to insure quality cutting.
3. Diameter of a diamond saw blade is 400 mm (Which can Replace with 300 mm, 350mm & 450 mm As Per Requirement).
4. Machine provides vibrationless operation wich gives precision cutting angle.
5. Machine consumes less power for operating.
6. For security purpose; In the case of Over Voltage Machine is treap Automatically.
7. Janatics brand Pnumatic Clamping system for hold the cutting material.
8. Pnumatic system provide with FRL unit.
9. In case of cutting of power supply; clamping system is not release the pressure.
10. For Up and down operation of blade; Standerd Equiped with Road – Bush & Helical Rack-Pinion System.
11. 25 mm Base plate makes with Grinding and hard chrome process.
12. PLC base Automation Delta brand software panel wich is online repairable.
13. 7 inch digital display with auto adjust speed of cutting and auto capture of cutting material’s hight measurement.
14. Automatic Inbuilt Diesel Spray wich Increase life of saw blade,gives smoodh & mirror finish cutting.
15. Indicator light for availibility of Diesel.
16. Saw blade cover system protect blade & collect waste aluminium particles in the tray.
17. Comply with branded SKF bearing with machine.
18. This is ideal machine to cut uneven & odd shaped profile due to 4 Pnumatic clamp position setting.
19. Machine is equipped with the 2 Horizontal & 2 Verticle Pnumatic clamp for Optimum grip.
20. linear motion on rack pinion base nylone roller track that gives acurate and fast measurement setting on profile to cut.
21. Machine deliver with Tool kit & blow air gun.
22. In optional extra accesories: Automatic saftey cover.

Technicial Specifications:
